- SPECIFICATION
|
Model NO. |
KBCD20HTC500FEH |
|
Video Output Mode |
AHD/TVI:5M@20fps/12.5fps, 2M@30fps, 2M@30fps; CVI: 2M@30fps, 2M@30fps |
|
Camera |
|
| Image Sensor | 1/3″ CMOS Sensor |
| Image Resolution | 5M:2592*1922 2M:2560*1220
2M:1920*1080 |
| Electronic Shutter | AUTO |
| TV System | PAL/NTSC |
| Scanning System | Progressive Scan |
|
Lens |
|
| Focus Length | Board Lens 3.6mm |
| Focus Control | Fixed |
| Lens Type | Fixed |
|
Night Vision |
|
| IR Cut Filter | YES |
| Infrared LED | 12µ x 18PCS |
| Infrared Distance | 20M |
| IR Status | AGC Auto Control |
| Camera Features | |
| Starlight | / |
| Day/Night | YES |
| OSD Menu Language | YES |
| White Balance | AUTO / MANUAL |
| Gain Control | AUTO |
| Noise Reduction | DNR |
| WDR | DWDR |
| UTC | YES |
|
General |
|
| Housing | IP67 |
| Bracket | YES |
| Operation Temperature | -10℃ ~ +60℃ RH95% Max |
| Storage Temperature | -20℃ ~ +60℃ RH95% Max |
| Power Source | DC12V±10%,550mA |
| Dimension | 151(W) x 62(H) x 65.5(D)mm |
| Weight | 700g |
